Chapter 5 Maintenance
5-58 3BSE 002 415R701 Rev A
TC560V1 No jumpering - On-line replacement possible however not
practical. Reflect the consequences to all
S100 I/O boards. The outputs will be forced
to the safe position (0 V, open contact). You
are recommended to switch off the mains
supply during the replacement.
The connection unit TK560 may be removed
from the modem without interrupting the
communication to other “nodes” on the near-
side bus.
For replacement of TC560 when S100 I/O bus redundancy is
used, see Section 5.5.10.3, Replacement of Redundant S100 I/O
Bus Extenders.
- Described in:
S100 I/O Hardware
TC561V1 No jumpering - On-line replacement possible however, not
practical. Reflect the consequences to all
S100 I/O boards. The outputs will be forced
to the safe position (0 V, open contact). You
are recommended to switch off the mains
supply during the replacement.
For replacement of TC561 when S100 I/O bus redundancy is
used, see Section 5.5.10.3, Replacement of Redundant S100 I/O
Bus Extenders.
- Described in:
S100 I/O Hardware
Table 5-1. Replacement Aspects of Individual Board Types (Controller Hardware) (Continued)
Board type - Jumpering Comments
