ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Section 5.5.10 User Repair
3BSE 002 415R701 Rev A 5-57
PM511V08
PM511V16
(PM511V on
the front)
No jumpering - This is the processor module of the
controller. On line replacement of a single
module is from a functional standpoint of
course not possible. However
the power supply need not be switched off.
Replacement of a redundant processor
module is described in Section 5.5.10.2, Replacement of
Redundant Processor Module
- Module described in: Appendix A
SB510 No jumpering - On-line replacement possible,
however, not during a mains supply
interruption while the battery is used.
See Section 5.5.10.6, Replacement of Backup Power Supply.
- Described in:
Appendix A, Hardware Modules
SB511 No jumpering - On-line replacement possible,
however, not during a mains supply
interruption while the battery is used.
See Section 5.5.10.6, Replacement of Backup Power Supply.
- Described in: Appendix A, Hardware Modules
SB522 No jumpering See Section 5.5.10.7, Battery Exchange
Described in: Appendix A, Hardware Modules
SC510 No jumpering - On-line replacement possible
- Described in: Appendix A, Hardware Modules
SC520 No jumpering - On-line replacement possible
- Described in: Appendix A, Hardware Modules
SR511 No jumpering - On-line replacement possible if a redundant
unit is available
- Described in: Appendix A, Hardware Modules
TC520 No jumpering - On-line replacement possible
- Described in: Appendix A, Hardware Modules
Table 5-1. Replacement Aspects of Individual Board Types (Controller Hardware) (Continued)
