ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Appendix E Current Consumption and Heat Dissipation
E-4 3BSE 002 415R701 Rev A
DSDO 115 0.65 22 mA/ch 7.8 With DSTD 108/108L
DSDO 115 0.65 - 7.7
DSDO 115A 0.27 - 11 With DSTD 110A,
DSTD 190V1
DSDO 115A 0.27 - 1.4 With DSTD 108P,
DSTD 108LP
DSDO 115A 0.27 - 1.4 With DSTD 109P
DSDO 115A 0.27 - 1.4 With DSTD 145, DSTD 147,
DSTD 148
DSDO 120 0.65 - 12.0
DSDP 140A 1.1 0.15 6.7
DSDP 150 1.0 - 7.0/7.8 Input/Output
DSDP 170 0.6 - 4
DSSR 122 - - 65.0 With max. load
DSSR 170 - - 23.0 With max. load
2
(1)
DSSS 171 - 0.1 6
DSBC 174 0.6 0.04 4.0 1
(2)
DSBC 176 0.6 0.04 4.0 1
DSTD 108P - 0.13 2.7 70% of all channels activated
DSTD 108LP - 0.13 2.7 70% of all channels activated
DSTD 109P - 0.045 9.5 70% of all channels activated
DSTD 145 - 0.36 8.3 70% of all channels activated
DSTD 147 - 0.36 11.5 70% of all channels activated
DSTD 148 - 0.36 13 70% of all channels activated
DSTD 195 - 0.045 1.6 70% of all channels activated
DSTD 196P - 0.16 3.3 70% of all channels activated
DSTD 197 - 0.045 2.9 70% of all channels activated
DSTD 198 - 0.045 3.3 70% of all channels activated
Sum
(1) Do not include redundant power supply units in the calculation of number of boards/units.
(2) Two per I/O subrack if redundant S100 I/O bus extension.
Table E-2. Current Consumption and Power Dissipation, S100 I/O Boards (Continued)
Type
Designation
Current Consump. (A)
Tot. Power
Dissipation (W)
Comments
No of
Boards
Total
I
tot
, P
tot
+5 V +24 V
