ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Section E.2 Calculation Algorithms and Forms with Technical Data
3BSE 002 415R701 Rev A E-5
Table E-3. Current Consumption and Power Dissipation, Power Supply and Sundry
Type
Designation
Current Consump. (A)
Tot. Power
Dissipation (W)
Comments
No of
Units
Total
I
tot
, P
tot
+5 V +24 V
SA1xx - - 100 Approx. for all types of
power supply units
(1)
(1) Redundant power supply units should not be included in the calculation of number of boards/units.
RC527 - 0.7 15 For three fans
TC512V1 - 0.1 2
TC513V1 - 0.1 2
TC514V2 - 0.1 2
TC515V2 - 0.1 2
TC516 - 0.1 2
TC560V1 - 0.24 5.6
TC561V1 - 0.28 6.6
TC562 - 0.13 3
TC570 - 0.02 0.5
TC625 - 0.13 3
TC630 - 0.1 2.4
Sum
