Section I.3 List of System Messages and Corrective Actions
3BSE 002 415R701 Rev A I-27
Table I-16. Type 134, Code
Type Code Significance Data 1 Data 2 Comments/Actions
134 20 AC 410/AC450, 24 V error Concept,
instance No.
MSW: Direction
LSW: Channel
H’EEEE
⇒
Error coming
H’2222
⇒
Equip. in working order
1
⇒
Channel 1
2
⇒
Channel 2
21 AC 410/AC450,
regulator error
MSW: Direction
LSW: Regulator
H’EEEE
⇒
Error coming
H’2222
⇒
Equip. in working order
AC450
0
⇒
Common reg. error (any/none
of 1 - 4 erroneous).
1
⇒
Regulator 1 error.
2
⇒
Regulator 2 error.
3
⇒
Regulator 3 error.
4
⇒
Regulator 4 error.
AC410
101
⇒
Regulator missing.
102
⇒
Regulator error.
22 AC 410/450,
battery error
MSW: Direction
LSW: Battery
H’EEEE
⇒
Error coming
H’2222
⇒
Equip. in working order
1
⇒
Battery A (Only AC 450)
2
⇒
Battery B (Only AC 450)
23 AC 410/450,
backup power supply error
MSW: Direction
LSW: Backup
power supply
H’EEEE
⇒
Error coming
H’2222
⇒
Equip. in working order
1
⇒
Unit A (Only AC 450)
2
⇒
Unit B (Only AC 450)
24 AC 410/450,
fan error
MSW: Direction
LSW: Not used
H’EEEE
⇒
Error coming
H’2222
⇒
Equip. in working order
25 AC 450,
I/O 24 V error
MSW: Direction
LSW: Channel
H’EEEE
⇒
Error coming
H’2222
⇒
Equip. in working order
1
⇒
Channel A
2 ⇒ Channel B
13:25:10 134 20
Type 134 System/Node Supervision
H’
H’11
1
H’
