6HFWLRQ *HQHUDO6\VWHP8WL OLWLHV
3BSE 002 415R701 Rev A 1-29
Fault
elements
Handle groups of fault signals for lamp
indication with flashing, acknowledgment
and alarm.
FAULT
Printing and text
generation
elements
Compose text strings and print reports. PRINT, TEXT
Elements for
functional units
Interface PC programs with
Advant Station 500 and MasterView 800
operator stations for control of motors,
valves and other process objects.
GENBIN-I, GENBIN-O,
GENUSD-I,
GENUSD-O
GENCON-I,
GENCON-O,
MOTCON, VALVECON,
MMC-IND, MMC-ORD
Switches Switch between two sets of data. SW, SW-C
Positioning
elements
Positioning and length-measuring
elements with both analog and on/off
outputs. Works with hardware module
DSDP 140A.
POS-A, POS-O, POS-L
Pulse counting
and frequency
measurement
elements
Synchronize the board DSDP 110 for
low-speed pulse counting. Pulse count-
ing and frequency measurement when
used with DSDP 150 and DSDP 170.
COUNT-DP, FREQ-MP,
FREQ-SP, PULSE-S,
PCU-COM, PCU-I,
PCU-O, PCU-SS
Pulse counting
and frequency
measurement
elements
Provide pulse counting and frequency
measurement with S800 module DP820.
DP820-I, DP820-O
Data handling Copy data from input to output. MOVE, MOVE-A
Event handling
elements
Create event text for MasterView 320. EVENT
Report elements Print reports in Advant Station 500 Series
Operator Stations.
REPORT
Elements for
programmable
module
Input and output elements for the
hardware module PU535.
FPM-COM, FPM-I,
FPM-IA, FPM-O,
FPM-OA
MasterView 100
elements
Elements for control of the panel units. DISP, DISP-SEG,
KEYB-FU, KEYB-GR,
KEYB-N1, NUM-IN
7DEOH 3&(OHPHQWVLQWKH%DVLF6\VWHP3URJUDP0RGXOH4&%$ 6&RQWLQXHG
7\SH )XQFWLRQ 3&HOHPHQW
