ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
&KDSWHU ,QWURGXFWLRQ
1-30 3BSE 002 415R701 Rev A
Weighing
elements
Interface strain-gauge scales with PC
programs in Advant Controller 400
Series.
SCALE, SCALE_DOS
Table handling
elements
Elements for handling data as tables. TBL-R, TBL-RG,
TBL-W, TBL-WG
Ramp
generators
Ramp generator with S-shaped output. RAMP-S1
Supervision
elements
Evaluate the load on Advant
Controller 400 Series and Advant
Controller 100 Series, element for con-
necting of supervisory signals from Mas-
terNet to AMPL program.
ANALYSE, COM-STAT
PROFIBUS-DP
communication
elements
Provide communication on
PROFIBUS-DP
PB-R, PB-S, PB-DIAG
LONWORKS
Network
Communication
elements
Provide communication on LONWORKS
Network
LON-R, LON-S
MasterFieldbus
communication
elements
Provide communication with
MasterPiece 51, MasterPiece 90,
Advant Controller 110, TYRAK or SAMI
via MasterFieldbus.
COM-CVI1,
COM-CVO1,
COM-MP51,
MFB-OUT, MFB-IN
Advant
Fieldbus 100
communication
elements
Provide fast communication with
other AC 400 Series nodes and Motor
Drive Control.
DSP-R, DSP-S,
DRI-CNV, DRI-R,
DRI-S
Data Set
elements
Initiate execution of Data Sets. SENDREQ
7DEOH  )XQFWLRQDO8QLWVLQ3URJUDP0RGXOH4&%$6
)XQFWLRQDOXQLW 'HVFULSWLRQ
AI Analog input signal, including AI, Temp (Pt100), TC (thermo-
couple), AIC (calculated AI) and pulse counter (DSDP 110)
AO Analog output signal, including AO and AOC (calculated AO)
DI Digital input signal, including DI and DIC (calculated DI)
DO Digital output signal, including DO and DOC (calculated DO)
DAT General data base value
7DEOH 3&(OHPHQWVLQWKH%DVLF6\VWHP3URJUDP0RGXOH4& %$6&RQWLQXHG
7\SH )XQFWLRQ 3&HOHPHQW
