Winder
3ADW000379R0501 DCS550 Manual e e
Direct tension control
Direct tension control (load cell control) is a closed loop control for the tension. The actual tension is
measured by means of a load cell and fed into the drive via analog input (AI3) and PID controller in group 40.
The speed controller stays active, but is saturated. Following parameters are set when using WinderMacro
(61.01) = DirectTens:
Parameter name
DirectTens
Factory (default)
Ref1Sel (11.03)
AI1
SpeedRef2301
TorqMaxSPC (20.07)
120 %
325 %
TorqMinSPC (20.08)
-120 %
-325 %
IndepTorqMaxSPC (20.24)
325 %
325 %
IndepTorqMinSPC (20.25)
-10 %
-325 %
SpeedCorr (23.04)
0 rpm
0 rpm
SpeedRefScale (23.16)
100 %
100 %
TorqSel (26.01)
Speed
Speed
TorqMuxMode (26.04)
TorqSel2601
TorqSel2601
LoadComp (26.02)
0 %
0 %
KpPID (40.01)
1
5
TiPID (40.02)
1000
2500
PID Act1 (40.06)
517 = AI3 ValScaled (5.17)
0
PID Ref1 (40.13)
6315 = TensionRef (63.15)
0
PID OutMin (40.16)
-10 %
-100 %
PID OutMax (40.17)
10 %
100 %
PID OutDest (40.18)
0
0
PID ReleaseCmd (40.23)
Auto
Auto
WriteToSpdChain (61.02)
Auto
Auto
WindUnwindCmd (61.04)
WindCtrlWord
WindCtrlWord
TopBottomCmd (61.05)
WindCtrlWord
WindCtrlWord
WinderOnCmd (61.06)
DI1
Auto
TensionOnCmd (61.07)
Auto
Auto
WindSpdOffset (61.14)
150 rpm, connected to SpeedCorr (23.04)
0
DiaLineSpdIn (62.01)
202 = SpeedRef2 (2.02)
202 = SpeedRef2 (2.02)
DiaMotorSpdIn (62.02)
104 = MotSpeed (1.04)
104 = MotSpeed (1.04)
DiameterSetCmd (62.04)
DI2
NotUsed
AdaptKpDiaActIn (62.10)
6208 = DiameterAct (62.08)
6208 = DiameterAct (62.08)
AdaptKpOutDest (62.13)
2403 = KpS (24.03)
0
AccActIn (62.17)
216 = dv_dt (2.16)
216 = dv_dt (2.16)
InerDiaActIn (62.23)
6208 = DiameterAct (62.08)
6208 = DiameterAct (62.08)
InerAccActIn (62.24)
6221 = AccActAdjust (62.21)
6221 = AccActAdjust (62.21)
InerReleaseCmd (62.28)
Auto
Auto
TensRefIn (63.01)
516 = AI2 ValScaled (5.16)
0
TaperDiaActIn (63.02)
6208 = DiameterAct (62.08)
6208 = DiameterAct (62.08)
TensValueIn (63.03)
0
0
TensSetCmd (63.04)
Auto
Auto
TensRampHoldCmd (63.09)
RelTensRamp
RelTensRamp
TensPulseCmd (63.13)
Auto
Auto
TTT Ref1In (63.18)
309 = PID Out (3.09)
0
TTT Ref2In (63.19)
6315 = TensionRef (63.15)
6315 = TensionRef (63.15)
TTT Ref3In (63.20)
0
0
TTT DiaActIn (63.22)
6208 = DiameterAct (62.08)
6208 = DiameterAct (62.08)
FrictMotorSpdIn (63.31)
104 = MotSpeed (1.04)
104 = MotSpeed (1.04)
FrictReleaseCmd (63.32)
Auto
Auto
Add1OutDest (64.01)
2024 =IndepTorqMaxSPC (20.24)
0
Add1In1 (64.02)
6324 = TensToTorq (63.24)
6324 = TensToTorq (63.24)
Add1In2 (64.03)
0
0
Add1ReleaseCmd (64.04)
Auto
Auto
Add2OutDest (64.08)
2602 = LoadComp (26.02)
0
Add2In1 (64.09)
6230 = InertiaComp (62.30)
6230 = InertiaComp (62.30)
Add2In2 (64.10)
6334 = FrictionComp (63.34)
6334 = FrictionComp (63.34)
Add2ReleaseCmd (64.11)
Auto
Auto
