ABB DCS550 User Manual

253
Signal and parameter list
3ADW000379R0501 DCS550 Manual e e
Signal / Parameter name
min.
max.
def.
unit
83.04 TimeLevSel (time level select)
Selects the cycle time for AP. This setting is valid for all function blocks.
0 =
Off no task selected
1 =
5ms AP runs with 5 ms
2 =
20ms AP runs with 20 ms
3 =
100ms AP runs with 100 ms
4 =
500ms AP runs with 500 ms
A136 NoAPTaskTime
[AlarmWord3 (9.08) bit 3] is set when TimeLevSel (83.04) is not set to 5 ms, 20 ms,
100 ms
or 500 ms but AdapProgCmd (83.01) is set to Start, SingleCycle or SingleStep.
Int. Scaling: 1 == 1 Type: C Volatile: N
Off
500ms
Off
-
83.05 PassCode (pass code)
The pass code is a number between 1 and 65535 to write protect AP by means of
EditCmd (83.02). After
using
Protect or Unprotect PassCode (83.05) is automatically set back to zero.
Attention:
Do not forget the pass code!
Int. Scaling: 1 == 1 Type: I Volatile: Y
0
65535
0
-
83.06 BreakPoint (break point)
Breakpoint for
AdapProgCmd (83.01) = SingleCycle.
The break point is not used, if
BreakPoint (83.06) is set to zero.
Int. Scaling: 1 == 1 Type: I Volatile: Y
0
16
0
-
Group 84: AP
84.01 AdapPrgStat (AP status word)
AP status word:
Bit
Name Value Comment
B0
Bit 0 1 AP is running
0 AP is stopped
B1
Bit 1 1 AP can be edited
0 AP cannot be edited
B2
Bit 2 1 AP is being checked
0 no action
B3
Bit 3 1 AP is faulty
0 AP is OK
B4
Bit 4 1 AP is protected
0 AP is unprotected
Faults in AP can be:
−
used function block with not at least input 1 connection
−
used pointer is not valid
−
invalid bit number for function block Bset
−
location of function block PI-Bal after PI function block
Int. Scaling: 1 == 1 Type: I Volatile: Y
-
-
-
-
84.02 FaultedPar (faulted parameters)
AP will be checked before running. If there is a fault,
AdapPrgStat (84.01) is set to “faulty” and FaultedPar
(84.02)
shows the faulty input.
Note:
In case of a problem, check the value and the attribute of the faulty input.
Int. Scaling: 1 == 1 Type: I Volatile: Y
-
-
-
-
84.03 LocationCounter (location counter)
Location counter for
AdapProgCmd (83.01) = SingleStep shows the function block number, which will be
executed next.
Int. Scaling: 1 == 1 Type: I Volatile: Y
-
-
-
-
