3.2.4 Expected component life
General
The expected life of a specific component of the robot can vary greatly depending
on how hard it is run.
Expected component life
NoteExpected life
i
Component
See note
iii
2,000,000 cycles
ii
Cables
Whichever occurs first:Cable chain
iv
2,000,000 cycles
v
or
18,000,000 gliding meters
vi
+ addition 18,000,000 gliding
meters if gliding shoes are
changed .
40,000 hoursGearbox
80,000,000 metersBall bearing blocks
i
The expected life of all componets is provided based on the typical cycle.
A typical cycle includes the robot IRB 2600 and track movement, starting from the initial position
(A) and going to maximum extension (B), and back (A). The cycle is a 12-meter movement (from
A to B to A, two 6-meter strokes) in 1 minute with the maximum acceleration 2.5 m/s
2
and maximum
payload 1.2 tons. Deviations from this cycle will result in differences in expected life!
ii
The track is dimensioned for a life of 4 years (302,400 cycles per year) in a normal application
iii
The expected life can also be affected by assemblage of cabling other than standard options.
iv
Due to process cycle variation and varying lengths of tracks the chains’ lifetime is calculated on
two parameters, gliding meters and bending cycles. When maximum limit of either parameter is
reached the complete chain and or cables should be replaced.
In order to maximize the chains lifetime ensure to optimize the software and cell layout to reduce
the amount of travel and cycles.
v
A cycle is comprised of two strokes / changes in direction.
vi
A gliding meter is described as the chain making contact with itself or the glide bars. Chains on
tracks shorter than 6 meters travel distance do not have gliding contact.
154 Product manual - IRBT 2005
3HAC051130-001 Revision: F
© Copyright 2015 - 2018 ABB. All rights reserved.
3 Maintenance
3.2.4 Expected component life
