7.5 Standard tools
General
All service (repairs, maintenance, and installation) procedures contains lists of
tools required to perform the specified activity.
All special tools required are listed directly in the procedures while all the tools
that are considered standard are gathered in the standard toolkit and defined in
the following table.
This way, the tools required are the sum of the standard toolkit and any tools listed
in the instruction.
Contents, standard tools
ToolQty
Ring-open-end spanner 8-19 mm1
Socket head cap 2.5-17 mm1
Torx socket no: 20-601
Torque wrench 10-120 Nm1
Ratchet head for torque wrench 1/21
Hex bit socket head cap no. 5 socket 1/2", bit length=20 mm1
Hex bit socket head cap no. 6 socket 1/2", bit length=20 mm1
Hex bit socket head cap no. 8 socket 1/2", bit length=20 mm1
Plastic mallet1
Small screwdriver1
276 Product manual - IRBT 2005
3HAC051130-001 Revision: F
© Copyright 2015 - 2018 ABB. All rights reserved.
7 Reference information
7.5 Standard tools
