Illustration/NoteAction
xx1400001587
A M6x12 Screw DIN6921,
9ADA181-11 (4 pcs)
Refit the side cover of the carriage.9
Refit the top cover.10
240 Product manual - IRBT 2005
3HAC051130-001 Revision: F
© Copyright 2015 - 2018 ABB. All rights reserved.
4 Repair
4.8.1 Replacing the felt gear
Continued
