5: Monitoring & Filtering
Parameter First choice Second choice
BWR set Optional N/A
PCP Direct
If this option is selected, the first and second choices are ignored. The PCP bits are forced to the default green or yellow
values based on the result of the bandwidth regulator or the pre-marking color. It should be noted that the pre-marking
color red is ignored if the default bandwidth regulator is not enabled.
Parameter First choice Second choice
Type
N/A N/A
CoS profile
N/A N/A
BWR set
N/A N/A
PCP mapping
If this option is selected, the first and second choices can be used to map and regulate traffic based on PCP / IP
precedence /DSCP values. The table below shows the valid configurations of the first and second choices.
Parameter First choice Second choice
Type VLANinVLAN
VLAN
IP precedence, DSCP
VLAN, IP precedence,
DSCP
IP precedence, DSCP
VLAN, VLANinVLAN
CoS profile
CoS profile CoS profile
BWR set Optional Optional
Encapsulation None
This option can be used to perform traffic regulation based on PCP / IP precedence /DSCP values. The selected CoS
profile in the first and second choices are ignored. The table below shows the valid configurations of the first and second
choices.
