14: Appendix B – MIB Support

14 Appendix B - MIB

Support

Public MIBs

The following public MIBs are supported:

RFC-1213-MIB

system group

interface group

snmp group

NOTE: Some groups have been removed for security reasons of the standard MIB-II.

IF-MIB

ifXTable

EtherLike-MIB

dot3StatsTable

dot3PauseTable

dot3HCStatsTable

RMON-MIB

etherStatsTable

etherHistoryHighCapacityTable

historyControlTable

etherHistoryTable

MAU-MIB

ifJackTable

ifMauAutoNegTable
