11: CFM
11 CFM
C
CFM continuity fault management
To view a list of all CFM instances and their settings, open the CFM > Stack tab.
CFM stack:
• Stack: Central location to view all the CFM information.
• Port: This object represents the Bridge Port or aggregated port on which MEPs might be configured.
• VID: VLAN ID to which the Maintenance Point is attached, or 0, if none.
• Level: MD level (or MEG level) of the Maintenance Point.
• Dir: Direction in which the Maintenance Point faces on the port.
• MID idx: The index of the Maintenance Domain to which the MP is associated, or 0 for MEGs.
• MA idx: The index of the Maintenance Domain to which the MP is associated, or 0 for MEGs.
• MEPID: The MEPID of the MEP.
• MAC address: MAC address of the Maintenance Point.
