iii
Differences Between the FOCUS 200B and the FOCUS 200 PLUS Systems
Item FOCUS 200B FOCUS 200 PLUS
Built-in Hardwired
Points
None 8 Hardwired Points
•
EOLR supervision using a 2k resistor
•
Support of normally-open or normally-
closed sensors
•
Up to 16 2-wire smoke detectors each
on points 1 and 2 (32 total)
•
Points 3 and 4 may be set for a style
“D” configuration
•
Point 8 may be configured as a bell
box tamper
Built-in Output
Triggers
None 8 Output Triggers
•
Each output may be programmed to
any of the output point types
•
May be used to trigger Long Range
Radio
•
May be used to trigger a relay
Dialer
•
Both a main and secondary dialer on a
communicator card
•
Supports ADT SIA (FSK) format only
•
Main dialer is built-in
•
Secondary dialer (472402A) is an add-
on module
•
Supports ADT SIA and ADEMCO
Contact ID formats
ADT AC
Communicator
Module
On the communicator card Add-on module (472491)
DES Encryption
Supported on the communicator card Not supported in this version
Service Telco Jack
Mounted external of the cabinet Located on the main PC board (Control
Unit)
Transformer
Supports 16.5VAC transformers only
•
16.5VAC (50VA) transformer provides
1A max output current
•
16.5VAC (82VA) transformer provides
2A max output current
Supports 18VAC and 16.5VAC
transformers
•
18VAC (50VA) transformer provides
1.5A max output current
•
18VAC (72VA) transformer provides
2.3A max output current
•
16.5VAC (50VA) transformer provides
1A max output current
•
16.5VAC (82VA) transformer provides
1.8A max output current
Note: Use 18VAC transformer for all
new installations. Use 16.5VAC
transformer for retrofit only.
