iv
Item FOCUS 200B FOCUS 200 PLUS
Relay Outputs
3 optional relay outputs (relays 1, 2 & 3)
• 2 built-in bell outputs (bell 1 & bell 2)
rated at 12VDC, 1.7A.
• Built-in auxiliary relay that may be
set for Dry (28VAC/VDC, 2.0A) or Wet
(12VDC, 1.7A) operation.
Built-in 4-Wire Smoke
Detector Reset
None Uses the auxiliary relay
• Set Jumper P3 for wet operation
• Program the relay output point type
for 4-wire smoke detector reset (output
point type 23)
Cabinet
FOCUS 200B cabinet Vista-100 cabinet
Wireless (RF) Support
None Supports all ADEMCO 5800 Series
transmitters except 5804BD, 5827BD, and
5827
Additional Point
Types
• Arming (65 - ARM) (RF devices only)
• Disarm (66 - DAR) (RF devices only)
• No Alarm Response (67 - NAR) (RF
devices only)
Cabinet Back Tamper
Not supported Supports back tamper for commercial
burglary applications
Cabinet Tamper
Mounted on the main PC Board Mounted on the side of the cabinet and
connects to the tamper input (J5 trigger 3)
Auto Cabinet Tamper
Bypass
Not supported Tamper is automatically bypassed when
the system goes into Service Mode
Primary Phone
Number Programming
Can only be edited via the downline loader Can be edited from either the downline
loader or the operational panel
Earth Ground Fault
Detection
None
Is a built-in function and is mapped to
point 245
SRAM
32k bytes
128k bytes
The FOCUS 200 PLUS System Installation Vital Information
Use the following table to record the vital information for this installation. We recommend you leave
this table with the control unit.
Job Location
System Number (SS)
Group Number (GG)
Instrument Number (II)
Service Terminal Phone Number
CCC Phone Number
ADT SIA (FSK) CID AC Module
CCC Communication Type
(check the
appropriate boxes)
