5702269-C I/O Communication and Control 4-71
Pinnacle™ Plus+ 10 kW
35
over-current
timer
Enables or disables an over-current timer and
specifies how long you want the power supply
to tolerate an over-current condition before
shutting off output.
• To enable the timer, send a value (2 bytes)
between 1 and 9999 (0.1 to 999.9 s)
• To disable the timer, send a value of 0
Read back with command 186.
2 CSR codes:
0,1,4,9
36
constant duty
cycle
Enables or disables the constant duty cycle
feature.
Send 1 byte:
•0 = Disable
• Non-zero = Enable
Read back with command 163.
1 CSR codes:
0,1,9
38
reset arc
density/run
counters
Resets micro-arcs-per-run and hard-arcs-per-
run counters to 0. These counters can be reset
at any time, and resetting them can be useful
for measuring arcs over a specific period of
time.
0 CSR codes:
0,1,9
40
AE Bus time-
out value
Specifies the amount of time the Pinnacle
Plus+ supply waits between bytes from the
host.
Send 2 data bytes (16-bit value); the value
represents increments of 10 ms and must be at
least 2 but no greater than 500 (20 ms to 5 s).
That is, two decimal places are implied (enter
500 for 5.00).
Read back this value with command 140.
2 CSR codes:
0,1,4,9
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
To Next Page
