4-72 I/O Communication and Control 5702269-C
Advanced Energy
®
43
sets synch
pulse as
transmitter or
receiver
Sets the unit’s synch pulse feature as a
transmitter or a receiver.
Send 1 data byte:
• 0 = Receiver
• Non-zero = Transmitter
Read back with command 163.
1 CSR codes:
0,1,2,9
44
panel text
line 1
Lets you write up to 40 characters of text to
line one (top line) of an active control panel
0 to 40 CSR codes:
0,9
45
panel text
line 2
Lets you write up to 40 characters of text to
line two (bottom line) of an active control
panel.
0 to 40 CSR codes:
0,9
46
erase panel
text
Erases text displayed with commands 44 and
45 and refreshes the display.
0 CSR codes:
0,9
You may set values for all three user output limits (commands 49, 50, and 51); however,
the Pinnacle Plus+ unit responds to the first limit value that impacts output.
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
