Advanced Energy Pinnacle Plus+ - Page 117

5702269-C I/O Communication and Control 4-73
Pinnacle™ Plus+ 10 kW
49
user power
limit
Sets a maximum limit for output power.
Send 2 data bytes (16-bit value); value must be
between 0 and the maximum rated output
power for the supply. 3 decimal places are
implied for a stand-alone unit (10000 = 10.000
kW) and 2 decimal places are implied for a
master/slave system (2000 = 20.00 kW).
Note: You cannot change the power limit when
output is on because this limit is used to
establish the type of operation: low or
high power. For values of 10% of the full
power or less, the operation mode is low;
for values greater than 10% of full power
the operation mode is high. (See
Chapter 6, “Operation,” for more
information).
Read back this value with command 141.
2 CSR codes:
0,1,4,9
50
user voltage
limit
Sets a maximum limit for output voltage as
measured at the DC inverter output (see Figure
2-1 on page 2-2).
Send 2 data bytes (16-bit value); value must be
between 0 and the maximum rated output
voltage for the supply.
Read back this value with command 142.
2 CSR codes:
0,1,4,9
51
user current
limit
Sets a maximum limit for output current.
Send 2 data bytes (16-bit value); value must be
between 0 and the maximum rated output
current for the supply. Assume 2 decimal
places (5000 = 50.00 A).
Read back this value with command 143.
2 CSR codes:
0,1,4,9
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
Page 117 of 204
Ex. 1024 Page 117
