5702269-C I/O Communication and Control 4-75
Pinnacle™ Plus+ 10 kW
66
enable or
disable
hard-arc
broadcast
Enable or disable the hard-arc broadcast
feature.
Send 1 data byte:
•0 = Disable
• Non-zero = Enable
Read back this setting with command 163.
1 CSR codes:
0,1,2,9
72
near end
(joule)
indication
Set a joule value to indicate the joule down
counter is near expiration.
Send 2 data bytes (16-bit value).
Read back this setting with command 232.
2 CSR only
73
joule count
reset
Resets the joules remaining counter to its initial
value while the output is on.
0 CSR only
74
enable/
disable joule
countdown
Enable or disable the joule countdown feature,
which waits for command 73 before beginning
the joule countdown.
Send 1 data byte:
•0 = Disable
• Non-zero = Enable
Read back this setting with command 163.
1 CSR only
84
redefine
PROFIBUS
status bits
Redefines the PROFIBUS status bits.
Send 1 data byte:
• 0 = Normal format
• Non-zero = Joule recipe definition
1 CSR only
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
