4-76 I/O Communication and Control 5702269-C
Advanced Energy
®
85
change
configuration
option bit
Changes the configuration option bit. Requires
2 data bytes.
1st data byte - Bit setting:
• 0 = Clear bit
• Non-zero = Set bit
2nd data byte - Configuration option bit
number (valid entries = 0-31):
• 7 = RAMP RESOLUTION
• 8 = JOULE RECIPE STATUS
• 18 = USER-PORT EOTL DEFINED AS
READY SIGNAL
• 19 = HIGH SPEED AEBUS
• 25 = EXPLICIT FAULT CLEARING
2 CSR only
92
pulse
frequency
index
Sets pulse frequency from 0 to 350 kHz (in
5 kHz increments):
Note: Frequency is limited to 150 kHz when
the pulse mode is set to be enabled
always.
• 0 = Pulsing disabled
•1 = 5 kHz
• 2 = 10 kHz
• 3 = 15 kHz
• 4 to 69 = (follow the established pattern)
• 70 = 350 kHz
Read back this setting with command 146.
1 CSR codes:
0,1,4,9
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
