5702269-C I/O Communication and Control 4-77
Pinnacle™ Plus+ 10 kW
93
pulse reverse
time
Sets pulse reverse time from 0.4 µsto 5.0 µs (in
0.1 µs increments):
• 04 = 0.4 µs
• 05 = 0.5 µs
• 06 = 0.6 µs
• 07 to 49 = (follow the established pattern)
• 50 = 5.0 µs
Read back this setting with command 147.
1 CSR codes:
0,1,4,9,33
119
master reset
Send this command to clear fault indication
when the Pinnacle Plus+ supply has
experienced a non-recoverable fault.
Note: Output will be turned off.
This request is always honored, regardless of
which interface has control.
0 CSR codes:
0,9
126
reset default
settings
Resets all user-defined values to their factory
defaults and stores them in non-volatile
memory.
Send one data byte with a value of 0.
1 CSR codes:
0,1,2,9
127
write to
scratch pad
Lets you write up to 40 ASCII characters to a
scratch pad memory (non-volatile).
Retrieve this information with command 131.
0 to 40 CSR codes:
0,9
Commands 128 through 255 request a value to be read from the Pinnacle Plus+ unit. Some
of these commands may return CSR codes.
128
request
supply type
Requests the power supply type; the returning
packet contains 4 ASCII characters: “PLUS”.
04
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
