4-78 I/O Communication and Control 5702269-C
Advanced Energy
®
129
request
supply size
Requests the output capacity of the power
supply; the returning packet contains 6
characters indicating capacity in kilowatts.
The data string implies 3 decimal places for a
stand-alone unit (10000 = 10.000 kWh) and
implies 2 decimal places for a master/slave
system (120000 = 1200.00 kWh).
06
130
request
maximum
unit limits
Reports the maximum limits for this unit; the
returning packet contains three (16-bit) values
for: power, voltage, and current limits.
06
131
request
scratch pad
memory
Displays most recent entry (40 characters) to
scratch pad memory.
Set with command 127.
040
136
request joule
threshold
Requests the output level that needs to be met
before the Joule output energy calculation
begins.
This level is set with command 26. The joule
threshold type (power, voltage, or current) is
set with command 64.
02
140
request
AE Bus time-
out value
Requests the AE Bus time-out value; the
returning packet contains 2 data bytes (16-bit
value) indicating the time in ms (a value of 2
indicates 20 ms).
This value is set with command 40.
02
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
