5702269-C Troubleshooting and Global Customer Support 7-9
Pinnacle™ Plus+ 10 kW
H004
Continued
from
previous
page
Ramp Time Out
of Range
You have attempted to set
ramp time to a value outside
the allowable range.
Retry setting the ramp time
using an acceptable value.
See the “I/O Communication
and Control” chapter for
more information.
Run Time Out of
Range
You have attempted to set
run time to a value outside
the allowable range.
Retry setting the run time
using an acceptable value.
See the “I/O Communication
and Control” chapter for
more information.
Joule Setpoint
Out of Range
You have attempted to set
the joule set point to a value
outside the allowable range.
Retry setting the joule set
point using an acceptable
value. See the “I/O
Communication and
Control” chapter for more
information.
Joule Threshold
Out of Range
You have attempted to set
the joule threshold to a
value outside the allowable
range.
Retry setting the joule
threshold using an
acceptable value. See the “I/
O Communication and
Control” chapter for more
information.
H005 Invalid Control
Mode
You have attempted to set a
control source other than
Local, Host, or User.
Set the control source to
Local, Host, or User.
Invalid
Regulation
Mode
You have attempted to set
the regulation mode to
something other than power,
current, or voltage.
Note: Output power must be
off (that is, output
must be de-energized)
to switch between
regulation modes.
Set a valid mode for
regulation (that is, power,
current, or voltage). See the
“I/O Communication and
Control” chapter for more
information.
Invalid
Parameter
You have attempted to set
an operating parameter to a
value outside its allowable
range.
Set a valid value for the
parameter. See the “I/O
Communication and
Control” chapter for more
information.
Table 7-3. Help Code Troubleshooting Table (Continued)
Help
Code
Number
Help Code
Message
Problem Indicated Suggested Action
To Next Page
