5702269-C Troubleshooting and Global Customer Support 7-11
Pinnacle™ Plus+ 10 kW
H019 Can’t Change
While Recipe is
Active
You have attempted to
initiate a unit function that is
not allowed while the power
supply is executing a recipe.
Delay initiating the desired
function until the recipe is
complete. Or turn off output
and disable the recipe
function before attempting to
initiate the desired function
again. For more information,
see the “I/O Communication
and Control” chapter.
H021 Joule Delivery
Not Complete
The joules delivered counter
is enabled and running and
you have attempted to turn
off output power before the
counter expired.
Delay initiating the desired
function until the joule
counter expires. Or turn
disable joule mode and then
shut off output power. For
more information, see the
“I/O Communication and
Control” chapter.
H025 Configured as a
Slave Unit
You have attempted to
initiate a unit function that is
not allowed while the power
supply is configured as a
slave.
De-assert the slave status of
the unit and retry the
function. For information
regarding this procedure, see
“Master/Slave Operation” in
chapter 5 of this manual.
H026 Can’t Change:
in Master/Slave
System
You have attempted to
initiate a unit function that is
not allowed while the power
supply is configured in a
master/slave system.
Disable the master/slave
system and retry initiating
the unit function. For more
information on this
procedure, see “Master/Slave
Operation” in chapter 5 of
this manual.
H028 Setpoint Out of
Range
You have attempted to set a
set point to a value outside
the allowable range.
Retry setting the set point
using an acceptable value.
See the “I/O Communication
and Control” chapter for
more information.
Table 7-3. Help Code Troubleshooting Table (Continued)
Help
Code
Number
Help Code
Message
Problem Indicated Suggested Action
