1.
X-ray tube
2.
Focal spot label [—]
3.
Significant zone of occupancy.
Minimum area 60x60 cm.
Minimum height above the floor 200 cm.
4.
Dose meter
5.
Protective device
6.
Wall
7.
DR Detector or cassette
8.
Significant zone of occupancy at the right side of the radiographic wall
stand
9.
Significant zone of occupancy at the left side of the radiographic wall
stand
Figure 16: Significant zones of occupancy at the radiographic wall stand
CAUTION:
The radiation protection has to be applied for the patient and for
the operator.
Related Links
Radiation Protection on page 35
Scattered radiation (general radiography) on page 41
