Agilent Technologies 7820A Service Manual

Agilent 7820 GC Service
159
Inlet example
The configuration control table for a front SSL Inlet includes 4
items.
CONFIGURE FRONT INLET
Configured:
Split/Split
less
Ignore Ready =
FALSE
Makeup gas type
He
[ EPC1 ] = (INLET)
(SS)
This list interprets each line of the control table.
 Configured: The type of module configured as a front inlet is
an split/splitless capillary inlet.
 Ignore Ready: If TRUE, the GC will ignore a Not Ready
status. If the inlet actuals do not match their setpoints, the
GC will go ready. The ignored items are displayed under
Status.
 This line indicates the EPC module. In this case, it is plugged
into the 4-wire connector labeled EPC1 and is an inlet EPC
module for an split/splitless inlet.
Detector example
The configuration control table for a front FID detector includes 9
items.
CONFIGURE FRONT DETECTOR
Configured:
(FID)
Ignore Ready =
FALSE
Makeup gas type
N2
Lit offset
2.0
Ignore Ignitor=
FALSE
Signal: Column
Comp
OFF
[ F-DET ] =
(SIGNAL)
(FID)
[ EPC3] = (DET_EPC)
(FID)
