Agilent Technologies 7820A Service Manual

322
Agilent 7820 GC Service
FID Base Assembly
Item
Description
Part number
Qty
1
Base spanner nut
19231-20990
1
2
Thermal strap
G1531-00105
1
3
Screw, captive, M3, T-10
G1946-20168
3
O-ring, size 2-006, fluorocarbon,
12/pk
5180-4181
3
4
Jets: see consumables
1
5*
FID base weldment with jet for new
version detector
FID base weldment with jet for old
version detector
G3431-80509
G4331-67000
1
1
6
Screw, M4 × 25 mm, Torx T-20
0515-2712
2
7
FID block insulation
G1531-60700
1
8
Adaptable FID column adapters:
1
– FID/NPD capillary column
19244-80610
--
– FID/NPD 1/8-inch packed
column
19231-80520
--
– FID/NPD 1/4-inch packed
column
19231-80530
--
9
Nut warmer insulation and cup
assembly (includes cup and
insulation)
19234-60720
1
10
Heater/sensor assembly
G1530-61950
1
Nut warmer insulation
19234-60715
*G3431-80509 New version FID base weldment, connected
to EPC with tubing blocks, includes jet 19244-80560
*G4331-67000 Old version FID base weldment, connected
to uEPC with thumb nuts, includes jet 19244-80560
