Agilent Technologies 7820A Service Manual

Agilent 7820 GC Service
281
Power diagnostics
This information is based on Service Mode | Diagnostics |
Electronics | Power Info.
POWER DIAGNOSTICS
Front inl:
72.5W
39.8
C
****%
Front det:
74.2W
40.8
C
****%
Aux 1:
0.5W
----
----
C
****%
Back inl:
72.5W
39.8
C
****%
Back det:
74.2W
40.8
C
****%
Logic current
1.37x
amps
Valve current
0.176
amps
24 Volts
26.66
volts
-24 Volts
-27.03
volts
Zone supply
42.92
volts
Primary
voltage
99.7%
The examples were taken from a GC with no auxiliary heaters
configured.
Note that the power display shows real-time percentages.
