Agilent Technologies 7820A Service Manual

Agilent 7820 GC Service
387
Electrical
This section contains illustrated parts breakdowns for the
following GC electrical components.
 Electronics carrier
 Keypad and display
 AC power
 AC power components
 AC board components
 Transformer
 Power cords
 Chassis Fans
Electronics carrier
Ite
m
Description
Part number
Qty
1
Harness, inlet/detector heater
G4350-60535
1
2
Grounding screw, M4 x 12 mm, T-20 (for #6)
0515-2496
1
3
Screw, M4  6 mm
0515-2832
10
4
Harness, flapper/oven sensor, etc.
G3430-60512
1
5
Analog & Power board
G4350-61150
1
6
Communication harness
G4350-60513
1
7
ALS Controller board
G4350-63529
1
8
Logic board
G4350-60101
1
9
Harness, keyboard and display
G4350-60001
1
NS
Fuse, ALS controller PCA, 7A 125 V
2110-0961
1
NS
Screw, M4 x 12 mm, to attach ALS board to
chassis
0515-2496
2
