Agilent Technologies 7820A Service Manual

374
Agilent 7820 GC Service
Oven
This section contains illustrated parts breakdowns for the
following GC components:
 Oven
 Oven flapper assembly
Oven assembly
Ite
m
Description
Part number
Qty
1
Fan blade, stainless steel, and set
screw
05890-80270
1
2
Oven heater shroud assemblies:
1
–100V Power
G1530-61610
–120V Power
G1530-61610
–200V Power
G1530-61640
–220V Power, 16 amp
G1530-61640
–220V Power, 10 amp
G1530-61230
–230V Power
G1530-61640
–240V Power
G1530-61640
3
Screw, M4, Torx T-20, chrome plated
0515-2711
4
4
Oven motor assembly
G1530-67030
1
5
Hex nut
0535-0043C
3
6
Washer
2190-0712
6
7
On/Off switch rod
G3430-40023
1
8
Sensor, door assembly
G1530-80670
1
NS
Column hanger
1460-1914
9
Capillary column spring clip
G1530-01340
4
10
Capillary column spring clip screws,
(M4 x 12mm)
0515-2711
4
