Agilent Technologies 7820A Service Manual

Agilent 7820 GC Service
327
Thermal Conductivity Detector (TCD)
Item
Description
Part number
Q
t
y
1
Screw, M4 × 12 mm, T-20
0515-2496
2
2
Thermal cover and insulation assembly
G1532-00027
1
3
Screw, M4 × 12 mm, T-20
0515-2496
1
4
Screw, M4 x 20 mm, T-20
1390-1024
1
5
O-ring, fluorocarbon, size 2-006,
12/pk
5180-4181
2
6*
TCD Block assembly, with reference gas
switching valve, without Delta PRT. Not
orderable.*
1
7
Column adapters, ferrules, and nut
8
TCD Insulation Cup Kit
G3432-00004
1
9
TCD mounting pallet. Not orderable.
(G3430-00067)
1
10
Heater/Sensor assembly
G1530-61950
1
11
Cylindrical EMI suppressor, ferrite
9170-1730
1
12
Silicone tubing. Not orderable.
(0890-1664)
13
Screw, M4 x 10 mm, T-20
0515-2711
2
14
Screw, M4 × 12 mm, T-20
0515-2496
2
*G3431-
*G4332-60504 New version TCD block assembly, connected
to EPC with tubing blocks. Not orderable.
* G4332-60504 Old version TCD block assembly, connected
to EPC with tubing blocks. Not orderable.
