Agilent Technologies 7820A Service Manual

284
Agilent 7820 GC Service
This section describes the following circuit boards and their
connections.
Some connectors are marked MTC, which stands for
Manufacturing Test Connector. There may or may not be a
connector loaded on the board. MTCs are used at the factory to
connect to test equipment so that the board can be exercised
without the need for a GC. These connectors are not used when
the board is installed in an instrument.
Description
Part number
AC power board, 100/120V
G4350-61060
AC power board
200/220/230/240V
G4350-61050
Analog and power board
G4350-61150
Logic and communications
board
G4350-60101
Keyboard/display connection
board
G4350-60552
FID signal board
G3431-60020
TCD signal board
G3432-60015
uECD signal board
G3433-60020
FPD signal board
G3435-60010
NPD signal board
G3434-60021
FID electrometer board
G4331-60015
uECD electrometer board
G4333-60010
NPD electrometer board
G4334-60010
