Agilent Technologies 7820A Service Manual

346
Agilent 7820 GC Service
Capillary with
extended jet
(recommended)
G1534-80590
0.29 mm
(0.11 inch)
70.5 mm
Capillary
19244-80560
0.29 mm
(0.011 inch)
61.5 mm
Capillary, high-
temperature
19244-80620
0.47 mm
(0.018 inch)
61.5 mm
Packed
18710-20119
0.46 mm
(0.018 inch)
63.6 mm
Nuts, ferrules, and hardware for capillary columns
Column id
Description
Typical use
Part
number
.530 mm
Ferrule, Vespel/graphite,
0.8-mm id (10/pk)
0.45-mm and 0.53-mm
capillary columns
5062-3512
Ferrule, graphite, 1.0-mm id
(10/pk)
0.53-mm capillary
columns
5080-8773
Column nut, finger- tight
(for 0.53-mm columns)
Connect column to inlet
or detector
5020-8293
.320 mm
Ferrule, Vespel/graphite,
0.5-mm id (10/pk)
0.32-mm capillary
columns
5062-3514
Ferrule, graphite, 0.5-mm id
(10/pk)
0.1-mm, 0.2- mm,
0.25-mm, and 0.32-mm
capillary columns
5080-8853
Column nut, finger- tight
(for .100- to .320-mm
columns)
Connect column to inlet
or detector
5020-8292
.250 mm
Ferrule, Vespel/graphite,
0.4-mm id (10/pk)
0.1-mm, 0.2- mm, and
0.25- mm capillary
columns
5181-3323
Ferrule, graphite, 0.5-mm id
(10/pk)
0.1-mm, 0.2- mm,
0.25-mm, and 0.32-mm
capillary columns
5080-8853
Column nut, finger- tight
(for .100- to .320-mm
columns)
Connect column to inlet
or detector
5020-8292
.100 and .200
mm
Ferrule, Vespel/graphite,
0.37-mm id (10/pk)
0.1-mm and 0.2-mm
capillary columns
5062-3516
Ferrule, Vespel/graphite,
0.4-mm id (10/pk)
0.1-mm, 0.2- mm, and
0.25- mm capillary
columns
5181-3323
Ferrule, graphite, 0.5-mm id
(10/pk)
0.1-mm, 0.2- mm,
0.25-mm, and 0.32-mm
capillary columns
5080-8853
