Agilent 7820 GC Service
47
Remove the three screws holding the collector assembly to the
mounting pallet.
The next step exposes the interconnect spring. Be
careful not to touch or disfigure the spring while
working on the FID. Any dirt or bending will reduce
the sensitivity of your detector.
Lift and remove the assembly from the pallet.
