Result: The Virtual Switches List window is displayed.
...................................................................................................................................................................................................
2
Select the respective virtual switch and click Details.
Result: The Virtual Switch List Information window appears
...................................................................................................................................................................................................
3
Select the WAN port in the Port Membership field and click on Port Details.
Result: The Select Port Role screen is displayed.
...................................................................................................................................................................................................
4
Select the Port Role to be used for the WAN port.
Reference: Refer to “Flexible port role assignment” (p. 8-77).
Result: The Customer/Network Port Information (depending on the selected port
role) window is displayed.
...................................................................................................................................................................................................
5
Select the required PVID and the required Acceptable Frame Type.
...................................................................................................................................................................................................
6
Select the Default User Priority applicable for incoming packets..
...................................................................................................................................................................................................
7
If Then
the chosen Port Role is Customer Port, continue with Step 11.
the chosen Port Role is Network Port, continue with Step 8.
...................................................................................................................................................................................................
8
In the Virtual Switch Information window, select Network Port and click Port
Details
.
Result: The Network Port Information window appears.
...................................................................................................................................................................................................
9
Click Edit, select Network Port in Select Port Role window and then click Next.
Result: The Edit Network Port Information window appears.
...................................................................................................................................................................................................
10
Select enabled or disabled for GVRP and select enabled or disabled for STP Protocol
from the drop down list and click Ok.
...................................................................................................................................................................................................
11
Select the QoS mode. Either Default Profile or Flow Configuration are possible.
Traffic provisioning
Provisioning a virtual switch in spanning tree mode
....................................................................................................................................................................................................................................
365-312-807R7.2
Issue 4, May 2007
Alcatel-Lucent - Proprietary
See notice on first page
8-111
