110 Rockwell Automation Publication 750-UM006C-EN-P - March 2022
Chapter 4 Configure and Start Up the Drive
Synchronize the Drive
1. Right-click the drive in the Controller Organizer and select Properties
to open the Module Properties dialog box.
It will connect and compare the Logix project drive parameters to the
PowerFlex 755 drive parameters. Because we adjusted numerous
parameters in the previous steps to tune the drive and the motor, the
adjusted parameters in the drive appear.
2. Choose Use Physical and click OK to import the changes into the Logix
project.
3. After the parameters have uploaded into the Logix Designer application
project and the system is synchronized, save the Logix Designer
application program so the online and offline program match.
4. Click Yes to confirm that you want to save the project and upload the
new tag values.
