Rockwell Automation Publication 750-UM006C-EN-P - March 2022 53
Configure and Start Up the Drive Chapter 4
Use the PowerFlex 20-HIM-C6S HIM to Access Parameters
The drive has an enhanced drive HIM, and it can be used to access parameters
in the adapter.
1. Verify that all cables are connected properly to the drive (see Make
Connections on page 44).
2. Display the Status screen, which is shown on HIM power up.
3. Use the or key to scroll to the Port in which the embedded
EtherNet/IP adapter resides (always Port 13).
4. To display the Jump to Parameter # entry dialog box, press the PAR# soft
key.
5. Use the numeric keys to enter the desired parameter number, or use the
or soft key to scroll to the desired parameter number.
For details on how to view and edit parameters, see the PowerFlex
20-HIM-A6/-C6S HIM User Manual, publication 20HIM-UM001
.
Set the Adapter IP Address
The drive ships with its EtherNet/IP adapter rotary switches factory set to a
value of 999. Based on this setting, 13:36 [BOOTP] determines the source of
the adapters EtherNet/IP address. When the adapter IP address switches are
set to a value other than 001…254 or 888, 13:36 [BOOTP] determines the
source for the adapter node address.
Using Adapter Parameters
By default, the embedded EtherNet/IP adapter on a PowerFlex 755 Frame 2 is
configured to set its IP address, subnet mask, and gateway address by using a
BOOTP server. To use adapter parameters instead, you must first disable
BOOTP by using 13:36 [BOOTP]. Then set the associated adapter
parameters as described in the following subsections.
IMPORTANT Throughout this section, when directed to cycle power, use the 24V DC
control power circuit breaker shown in Figure 9 on page 52
.
IMPORTANT The On-Machine Drive cannot use a BOOTP server to set the node address
because of the 1783-ETAP dual-port Ethernet adapter.
