Rockwell Automation Publication 750-UM006C-EN-P - March 2022 205
Spare Parts Directory Appendix A
Servo Motor 24V DC
Mechanical Brake
SCHEMATIC SYMBOL PART DESCRIPTION CATALOG NUMBER
1EA030
(1)
(1) Refer to the drive data nameplate or Tables 1 or 2 on the schematics to select the drive size.
PowerFlex 755 Drive (Note 1) 20G11F****AA0NNNNN
1CH030 PowerFlex 750, Frame 2 EMC Kit 20-750-EMC1-F2
1EA030_DENCODER PowerFlex 750 Dual Encoder Option Module 20-750-DENC-1
1EA030_UFM PowerFlex 750 Universal Feedback Module 20-750-UFB-1
1EA030_STO PowerFlex 750 Network Safe Torque-Off Module 20-750-S3
1EA030_SSM PowerFlex 750 Network Integrated Network Safety
Functions Module
20-750-S4
1EA030_I/O PowerFlex 750 24V DC 1R2T I/O Module 20-750-2263C-1R2T
1EA030_APS PowerFlex 750 Auxiliary Power Supply Module 20-750-APS
1HIM320 PowerFlex IP66 / UL Type 4X Human Interface
Module (HIM)
20-HIM-C6S
1CB030 140G 125A Molded Case Circuit Breaker 140G-G6C3-C30-AJ
5CB130 1489 Miniature Circuit Breaker 1489-M2D040
5CB130_AUX 1489 Miniature Circuit Breaker Auxiliary Contact 1489-AMRA3
5BC130 IEC 9A Brake Contactor 100-C09EJ10
5BC130_SUP Contactor Coil Surge Suppressor 100-FSD250
5BC130_AUX Contactor Auxiliary Contact 100-SB01
1BD270 Brake Contact, RC Suppressor 199-MSMD1
5CB070 4 A Circuit Breaker 1489-M2D040
6ET210 Ethernet I/P Tap, 3 Port 1783-ETAP
ENET_DRIVE RJ45 Ethernet Media 1585J-M4TBJM-1
