Gland Plate Receptacles
SCHEMATIC SYMBOL PART DESCRIPTION CATALOG NUMBER
L123 Input Power Receptacle,IN1,M35,4 Pin SK-26G-RCPT-L123-M35-4
T123 Output Power Receptacle,M29,4 Pin SK-26G-RCPT-T123-M29-4
DBR Dynamic Brake Receptacle,M29,4 Pin SK-26G-RCPT-DBR-M29-4
T123 Output Power Receptacle,M35,4 Pin SK-26G-RCPT-T123-M35-4
DBR Dynamic Brake Receptacle,m35,4 Pin SK-26G-RCPT-DBR-M35-4
EMB1/EMB2 Mechanical Brake Receptacle,m24,3 Pin SK-26G-RCPT-EMB1-2-M24-3
CP 24V DC Control Power Recep,Mini,4 Pin SK-26G-RCPT-CP-MINI-4
CPBR 24C DC Brake Power Recep,Mini,4 Pin SK-26G-RCPT-CPBR-MINI-4
S0 S0 Network Safety Recep,A,Micro,5 Pin SK-26G-RCPT-S0-A-MICRO-5
S0 S0 Network Safety Recep,B,Micro,5 Pin SK-26G-RCPT-S0-B-MICRO-5
S1 S1 Network Safety Recep,B&C,Micro,5 Pin SK-26G-RCPT-S1-B-C-MICRO-5
S0 S0 Network Safety Recep,C,Micro,5 Pin SK-26G-RCPT-S0-C-MICRO-5
P0 P0 Digital Input Receptacle,Micro,5 Pin SK-26G-RCPT-P0-MICRO-5
P1 P1 Digital Input Receptacle,Micro,5 Pin SK-26G-RCPT-P1-MICRO-5
DBRT Brake Res Thstat Temp Recep,Micro,4 Pin SK-26G-RCPT-DBRT-MICRO-4
ETH1/ETH2 Micro D-code, QD Style Ethernet Media 1585D-D4TBJM-0M3
ENC0 INC Encoder Receptacle,M23,12 Pin,E41 SK-26G-RCPT-ENC0-E41-M23-12
HIPSC HIPSC Encoder Receptacle,M23,12 Pin,E42 SK-26G-RCPT-HIPSC-E42-M23-12
SSISC SSI SC Rotary Encoder Recp,M23,12 P,E43 SK-26G-RCPT-SSISC-E43-M23-12
DENC0 Dual INC Encoder 0 Recp,M23,12 Pin,E44 SK-26G-RCPT-DENC0-E44-M23-12
DENC1 Dual INC Encoder 1 Recp,M23,12 Pin,E44 SK-26G-RCPT-DENC1-E44-M23-12
HIPSC HIPSC Encoder Recp,M23,12 Pin,E51,E53 SK-26G-RCPT-HIPSC-E51-3-M23-12
SSIL SSI LIN Encr Recp,M23,12 Pin,E53,E54,E55 SK-26G-RCPT-SSIL-E53-4-5-M23-12
SSISC SSI SC Rotary Encoder Recp,M23,12 P,E56 SK-26G-RCPT-SSISC-E56-M23-12
CPBM
(1)
(1) Use with SK-26G-RCPT-CPBM-P10-B18-6.
Output Pwr,#10 & Brake,#18, Recp,6 Pin SK-26G-RCPT-CPBM-P10-B18-6
Mp-series Cable Bulkhead Adapter, 06CF 2090-KPB47-06CF
(4)
(4) This is a flange adapter to mount the receptacle SK-26G-RCPT-CPBM-P10-B18-6 on the gland plate.
CPBM
(2)
(2) Use with SK-26G-RCPT-CPBM-P14-B18-6.
Output Pwr,#14 & Brake,#18, Recp,6 Pin SK-26G-RCPT-CPBM-P14-B18-6
Mp-series Cable Bulkhead Adapter, 12CF 2090-KPB47-12CF
(5)
(5) This is a flange adapter to mount the receptacle SK-26G-RCPT-CPBM-P14-B18-6 on the gland plate.
CFBM
(3)
(3) Use with SK-26G-RCPT-HIPSC-E52-5-M23-17.
HIPSC Encoder Recp. Servo bulk H,E52,E55 SK-26G-RCPT-HIPSC-E52-5-M23-17
Mp-series Cable Bulkhead Adapter, CF 2090-KFB47-CF
(6)
(6) This is a flange adapter to mount the receptacle SK-26G-RCPT-HIPSC-E52-5-M23-17 on the gland plate.
