Rockwell Automation Publication 750-UM006C-EN-P - March 2022 15
Getting Started Chapter 1
ArmorConnect Power Media
The ArmorConnect® power media offers both three-phase and control power
cable systems. These include patchcords, receptacles, tees, reducers, and
accessories to be used with the drive. These cable system components create a
quick connection to the drive, reducing installation time. They provide for
repeatable, consistent connection of the three-phase and control power to the
drive and motor by providing a plug and play environment that also avoids
system mis-wiring.
Details of ArmorConnect power media are described in the ArmorConnect
Power and Control Media Selection Guide, publication 280PWR-SG001
.
To specify power media for use with the drive, use only motor and power cables
that are listed for use with the drive. See Select Cables
on page 38.
SHOCK HAZARD: Risk of electrical shock. Do not disconnect or connect
power cables under load.
ATTENTION: ArmorConnect cables are not intended to be connected or
disconnected under load. Physical injury or equipment damage will result
from the high make and break currents, and potential fault currents.
