Appendix A
Spare Parts Directory
Induction Motor 400/480 AC
Source Brake
Schematic Symbol Part Description Catalog Number
1EA030
(1)
(1) Refer to the drive data nameplate or Tables 1 or 2 on the schematics to select the drive size.
PowerFlex 755 Drive (Note 1) 20G11F****AA0NNNNN
1CH030 PowerFlex 750, Frame 2 EMC Kit 20-750-EMC1-F2
1CH031 1321 Common Mode Code 1321-M055
1EA030_ENCODER PowerFlex 750 Encoder Option Module 20-750-ENC-1
1EA030_DENCODER PowerFlex 750 Dual Encoder Option Module 20-750-DENC-1
1EA030_UFM PowerFlex 750 Universal Feedback Module 20-750-UFB-1
1EA030_STO PowerFlex 750 Network Safe Torque-Off Module 20-750-S3
1EA030_SSM PowerFlex 750 Integrated Network Safety Functions
Module
20-750-S4
1EA030_I/O PowerFlex 750 24V DC 1R2T I/O Module 20-750-2263C-1R2T
1EA030_APS PowerFlex 750 Auxiliary Power Supply Module 20-750-APS
1HIM320 PowerFlex IP66 / UL Type 4X Human Interface
Module (HIM)
20-HIM-C6S
1CB030 140G 125A Molded Case Circuit Breaker 140G-G6C3-C30-AJ
1CB250 140M/MT Brake Motor Protection Circuit Breaker 140M-C2E-B25/
140MT-C3E-B25
1CB250_AUX 140M/MT MPCB Auxiliary Contact 140M-C-AFA10/
140MT-C-AFA10
5BC130 IEC 9A Brake Contactor 100-C09EJ10
5BC130_SUP Contactor, Coil Surge Suppressor 100-FSD250
5BC130_AUX Contactor, Auxiliary Contact 100-SB01
1SUP270
(2)
(2) Contact your local distributor to order an Electrocube component.
Brake Contact, RC Suppressor ELECTROCUBE-RG1676-16
5CB070 4A Circuit Breaker 1489-M2D040
6ET210 Ethernet I/P Tap, 3 Port 1783-ETAP
ENET_DRIVE RJ45 Ethernet Media 1585J-M4TBJM-1
