Rockwell Automation Publication 750-UM006C-EN-P - March 2022 31
Prepare for Installation Chapter 2
Lift and Transport the Drive
All lifting equipment and components (hooks, bolts, lifts, slings, chains, and so
on) must be properly sized and rated to lift and hold the weight of the drive.
Read these precautions before attempting to lift a drive.
Follow theses steps to lift a drive to an upright position.
1. Optionally, for easier access to the drive, remove the T25 hexalobular
screws that secure the sides of the shipping container, and remove the
container sides.
2. Insert and secure the appropriate hardware in the designated lifting
holes (as shown in the illustration).
ATTENTION: All equipment and hardware that is used to lift the drive must
be properly sized and rated to lift and hold the weight of the drive safely. To
guard against possible personal injury or equipment damage:
• Inspect all hardware for proper attachment before a drive is lifted.
• Do not allow any part of the drive or lift equipment to contact electrically
charged conductors or components.
• Do not allow personnel or their limbs directly beneath the drive during a lift.
ATTENTION: To guard against death, serious personal injury, or equipment
damage, do not subject the drive to high rates of acceleration or deceleration
while lifting or transporting.
ATTENTION: To guard against equipment damage, verify that the hardware
is securely connected to the correct lifting holes in the drive as shown.
