Chapter 5 Drive Maintenance
Replace Receptacles on the
Gland Plate
There are six installation methods available for the gland plate receptacles.
Each method is based on the receptacle type.
For all receptacle types, these steps apply:
1. Follow the procedure to Remove Power
on page 146.
2. Follow the instructions to Remove the Front Cover
on page 148.
3. Disconnect incoming 400/480V AC power and the auxiliary 24V DC
power.
4. Disconnect the patchcords of all respective receptacles from the
enclosure side of the connector.
5. Go to the specific instruction for your receptacle type, complete
replacement, and return to these instructions.
IMPORTANT Many of the receptacles could appear to be interchangeable because they
have the same mounting hole pattern. Verify your pin out and connectors
before attaching to the On-Machine Drive. Review the electrical schematics
and receptacle abbreviations.
The receptacle groups that follow have similar mounting hole patterns but,
they are not interchangeable
• Encoder CFBM and Power Receptacle CPBM for <
14 amp
• M23 Encoders: ENC0, HIPSC, SSIL, DENC0, DENC1, and SSISC
• Power Receptacles: L123, T123, DBR, and EMB1
• Control Power Receptacles: CP, CPBR, and EMB2
• Safety Receptacles: S0 and S1
• Control Power Receptacle: P0, P1, and DBRT
ATTENTION: Risk of equipment damage or malfunction. Note the cable and
wire routing inside of the drive prior to removing any receptacle. The cable
and wire routing for the replacement receptacle must be the same as the
original.
To Next Page
