Rockwell Automation Publication 750-UM006C-EN-P - March 2022 165
Drive Maintenance Chapter 5
6. Torque receptacle to the corresponding torque.
7. Attach all removed patchcords and cables.
See Receptacle Connections
on page 47 for information on connection
order and pin out details. See the electrical schematics for additional
wiring information.
8. Follow the instructions to Attach the Front Cover
on page 169.
Terminal Designation Description Torque Value (lb•in)
L123 Input Power 60 ± 10%
T123 Output Power 60 ± 10%
DRB Dynamic Brake 60 ± 10%
EMB1 400/480V AC Source Mechanical Brake 45 ± 10%
EMB2 24V DC Mechanical Brake 45 ± 10%
CP 24V DC Control Power 45 ± 10%
CPBR 24V DC Brake Power 45 ± 10%
DBRT Brake Resistor Thermostat Temperature 45 ± 10%
SO S0 Safety (S3) 45 ± 10%
S0 S0 Network Safety (S4) 45 ± 10%
S0 S0 Network Safety (S4 with brake) 45 ± 10%
S1 S1 Network Safety (S4) 45 ± 10%
PO P0 Digital Input 45 ± 10%
P1 P1 Digital Input 45 ± 10%
CFBM
Allen-Bradley Servo Bulk Head Hiperface Encoder -
Bulk head adapter
11 ± 10%
Allen-Bradley Servo Bulk Head Hiperface Encoder -
Mounting screws
25 ± 10%
CPBM
Allen-Bradley Servo Motor Power and Brake - Bulk
head adapter
11 ± 10%
Allen-Bradley Servo Motor Power and Brake -
Mounting screws
25 ± 10%
ENCO M23 Incremental Encoder 133 ± 10%
HIPSC M23 Hiperface SC Encoder 133 ± 10%
SSIL M23 SSI Linear Encoder 133 ± 10%
DENCO M23 Dual Incremental Encoder - 0 133 ± 10%
DENC1 M23 Dual Incremental Encoder - 1 133 ± 10%
SSISC M23 SSISC Rotary Encoder 133 ± 10%
ETH1 EtherNet/IP Link 1 20 ± 10%
ETH 2 EtherNet/IP Link 2 20 ± 10%
