16 Rockwell Automation Publication 750-UM006C-EN-P - March 2022
Chapter 1 Getting Started
Catalog Number Explanation
a
b
c
d
e
f
g
h
i
j, k, l, m
n
o
p
q
r
s
Drive
Code Type
26G PowerFlex 755
Future Use
Code Description
1 Future Use
Input Type
Code Description
1 AC input with precharge, includes DC
terminals
Enclosure Type
Code Type
F UL Type 12 / IP66 (indoor use only)
Voltage Rating Class
Code Type
C400V AC, 50 Hz
D480V AC, 60 Hz
Normal Duty Drive Rating @ 400V AC, 50 Hz
Code Amps kW Frame
8P7 8.7 4 2
011 11.5 5.5 2
015 15.4 7.5 2
022 22.0 11 2
Normal Duty Drive Rating @ 480V AC, 60 Hz
Code Amps Hp Frame
8P0 8.0 5 2
011 11.0 7.5 2
014 14.0 10 2
022
(1)
(1) Option 022 for 22A, 15Hp, Normal Duty with induction
motor or Allen-Bradley® servo motor. Option 022 for 14A,
10Hp, Heavy Duty with Allen-Bradley servo motor only.
22.0 / 14.0 15 / 10 2
Filtering and Common Mode Cap Configuration
Code Filtering Default Connection
J Yes Jumper installed
Dynamic Braking (internal to drive)
Code Resistor Transistor
ANo Yes
Cover Mounted HIM
Code Type
4UL Type 4x / IP66
Future Use
Code Description
N Future Use
Safety Option Module - Slot 6
Code Type
A Network Integrated Safe Torque Off Module
(STO) S3
B
(1)(2)(3)
(1) Integrated Safety Function option module requires Studio
5000 V31.00 or higher firmware with Guard Logix 5580 or
Compact GuardLogix 5380 controllers for drive safety
functions.
(2) Options B and C require, at a minimum, selection of one of
the following options: E42, E43, E44, E51, E52, E53, E55,
E56.
(3) Option B provides two customer safety inputs, S0 and S1.
Network Integrated Safety Function (SSM) S4
C
(1)(2)(4)
(4) Option C uses the safety output S0 to provide control power
to the brake circuit and provides one customer input S1. The
S0 input is used internally to monitor the status of the
brake contactor.
Network Integrated Safety Function with
Brake Control (S4)
NNone
Motor Type
Code Motor
M1 Induction motor
M2
(1)(2)
(1) Option M2 selected with Drive Rating 022 configures the
drive for Heavy Duty (HD) rating.
(2) M2 and M3 are only available in 480V AC / 60 Hz.
Allen-Bradley MPL, MPM servo motor, for use
with 14 AWG or 16 AWG motor cable
M3
(2)(3)
(3) Option M3 for use with Drive Rating 022 only.
Allen-Bradley MPL, MPM servo motor, for use
with 10 AWG motor cable
Connector - AC Input Power and Control
Code Input Size / Type Control Size /
Typ e
IN1 M35 Allen-Bradley, 4-pin
male
Mini, 4-pin,
male
IN2 Future use Mini, 4-pin,
male
Brake Control Options
Code Brake Control
(1)
(1) Options SB and B2 are for use with AC induction motors.
Option B3 is for use with Allen-Bradley MPM and MPL servo
motors.
SB 400/480V AC source brake, M24 output
receptacle, 3-pin female. No additional
connector for brake
B2 24V DC brake, M24 output receptacle, 3-pin
female with 24V DC auxiliary power input,
mini 4-pin, male
B3 24V DC brake + servo motor output, M40 or
M23 output receptacle, 6-pin, female with
24V DC auxiliary power input, mini 4-pin male
Encoder Type - Slot 4
Code Type
(1)
(1) Option E41 is for use with the AC induction motors only.
Option E42, E43, and E44 are for use with the AC induction
and Allen-Bradley servo-motors.
Receptacle
E41 Incremental HTL, 12V
DC
M23, Female, 12-Pin,
20° Coded
E42 Hiperface SC M23, Female, 12-pin,
20° Coded
E43 SSI SC Rotary M23, Female, 12-pin,
20° Coded
E44
(2)
(2) Option E44 on-board P3 jumper is set to provide feedback
to an SSM Safety Option Module.
Dual Incremental
HTL, 12V DC
M23 (qty. 2), Female,
12-pin, 20° Coded
N None (Future Use) None (Future Use)
Encoder Type - Slot 5
Code Type
(1)
(1) Option E51, E53, E54, and E 56 are for use with AC
induction motors. Option E52 and E55 are for use with
Allen-Bradley servo motors.
Receptacle
E51 Hiperface SC M23, Female, 12-pin,
20° Coded
E52 Hiperface SC AB servo motor bulk
head
E53 Hiperface SC + SSI
Linear
M23 (qty. 2), Female,
12-pin, 20° Coded
E54 SSI Linear M23, Female, 12-pin,
20° Coded
E55 Hiperface SC + SSI
Linear
AB servo motor bulk
head + M23, Female,
12-pin, 20° Coded
E56 SSI SC Rotary M23, Female, 12-pin,
20° Coded
N None None
1…3 4 5 6 7 8…10 11 12 13 14 15 16 17
26G
1
1 F D 022 J A 4 N N N N
abcde ghif jklm
18 19 20
A -M1 -IN1
nop
21 22 23
-SB -E41 -E51
qrs
