Rockwell Automation Publication 750-UM006C-EN-P - March 2022 29
Prepare for Installation Chapter 2
Upon delivery of the drive, refer to the packing slip for sizes and exact shipping
weights. The packing slip will also list the items that are included in the
shipment. Inspect the shipment for damaged or lost items.
Crate Contents
The following is a list of items that are included in the crate:
• On-Machine Drive
• Electrical schematics specific to shipped unit
• Language labels
• Product Information, publication 750-PC004
• An envelope containing installation instructions for components
Table 3 - Product Weight and Dimensions
Condition Description (Approx)
Enclosure Dimensions (H x W x D) 609.6 mm x 609.6 mm x 274.4 mm (24 in. x 24 in. x 11 in.)
Product Dimensions (H x W x D) 711.2 mm x 649.8 mm x 391.9 mm (28 in. x 25.58 in. x 15.43 in.)
Packaging Dimensions (H X W x D)
with product inside
475 mm x 800 mm x 800 mm (18.69 in. x 31.5 in. x 31.5 in.)
Weight 47.62 kg (approx. 105 lb)
Weight with packaging 63.95 kg (approx. 141 lb)
IMPORTANT For drives that were in storage and did not have voltage applied,
maintenance of the capacitors in the drive may be required. For drives that
are stored under 2 years, there is no additional maintenance required. For
storage greater than 2 years, see Preventive Maintenance Checklist of
Industrial Control and Drive System Equipment, publication DRIVES-TD001
for bus capacitor reforming requirements or Table 9 on page 200
.
TIP To order additional copies of the electrical schematics, contact your local
Allen-Bradley distributor or Rockwell Automation sales representative.
