AT-TQ5403 and AT-TQm5403 Access Points User’s Guide
103
Note
The Link Aggregation Configuration section is explained in “Enabling
or Disabling the LAN2 Port” on page 104.
2. Configure the settings by referring to Table 21.
3. Click the SAVE & APPLY button to save and update the configuration.
Table 21. LAN Settings Window - VLAN Configuration Section
Parameter Description
Management
VLAN Tag
Select one of the following:
- Enabled: Activates the management VLAN.
- Disabled: Deactivates the management VLAN.
Management
VLAN ID
Enter a VLAN ID if Management VLAN Tag is set
to Enabled. Here are the guidelines:
- You can enter only one VID.
- The range is 1 to 4094.
- The default is 1.
- This field is hidden when Management VLAN
Tag is disabled.
