Chapter 4: 2.4GHz and 5GHz Radios
62
Configuring
Advanced Radio
Settings
To configure the advanced parameters for Radio1, Radio2, or Radio3,
perform the following procedure:
1. Select Settings > Radio from the main menu.
2. Select Radio1, Radio2, or Radio3 from the sub-menu. You can
configure only one radio at a time.
3. Click the Advanced Settings tab. Refer to Figure 17.
Figure 17. Advanced Radio Settings Window
4. Configure the parameters by referring to Table 10.
Table 10. Advanced Radio Settings Window
Field Description
Maximum
Clients
Use this option to specify the maximum number
of wireless clients that a radio will support at one
time. You might use the option to control the
distribution of clients over the radios. The
guidelines are given here:
- The range is 0 to 200 clients. The default is 200
clients.
- The AT-TQ5403 and AT-TQm5403 access
point can support a maximum of 200 and 127
clients, respectively, on all radios at one time.
